Image Sensor
1/3 Inch CCD
-
Effextive Pixels
NTSC/EIA(768(H)X494(V))
-
TV System
NTSC
-
Horz resolution
470 TV Lines
-
Video Outpus
Composite Video(1.0v
-
Frequency
Hor. NTSC : 15.743kHz
Ver. NTSC : 59.94kHz -
Scan type
2:1 Interace
-
Sync System
D Type Internal
A Type - AC Line Lock 60 V - phase Adjustment
C Type - N/A -
Min. Illumination
0.3 Lux
-
Shutter speed
NTSC/EIA(1/60 ~ 1/50000 Sec)
-
AGC Off
50dB or better
-
Video Outputs
Composite Video (1.0Vp-p / 75Ω)
Separated Y/C (Y;1Vp-p / 75Ω C;0.286Vp-p / 75Ω) -
Dip switch
AGC - On/Off
BLC - On/Off
Iris Control - Elc/Alc
Auto Iris Lens - Dc/Video
Sync System - N/A
Flikerless - On/Off -
Lens mount
C / CS Mount
-
Power
DC 12V
-
Humidity
30% ~ 85%
